MC-4 Solar PV Connector Male and Female Plug Connector Assembly Panel with certified MC 4 PV Connector
MC 4 Photovoltaic Connector
Order NO. Part P/N Cable Special
- Connector Terminal Conductor Size Cable OD
MC4-CMMM-14 MC4-CMMM-H MC4-CM-T14 AWG 14 (2.5mm2) Φ4.5-Φ8.5
MC4-CMMM-12 MC4-CM-T12 AWG 12 (4.0mm2)
MC4-CMMM-10 MC4-CM-T10 AWG 10 (6.0mm2)
Rated Current 30A (2.5-6mm2)
Rated Voltage 1000V DC
Test Voltage 6000V (50HZ, 1min)
Contact Resistance ≤ 1mΩ
Contact Material Copper, Tin-plated
Insulation Material PPO
Degree of Protection IP67
Flame Class UL94-V0
Temperature Range -40ºC ~ +125ºC
📸 Product Gallery
Connector Detail 1
Connector Detail 2
Connector Detail 3
Connector Detail 4
Connector Detail 5
Connector Detail 6
Connector Detail 7
Connector Detail 8
Connector Detail 9
❓ Frequently Asked Questions
What is the rated voltage and current for these MC4 connectors?
The connectors are rated for a voltage of 1000V DC and a current of 30A for cable sizes ranging from 2.5mm² to 6.0mm².
Are these connectors waterproof for outdoor use?
Yes, they feature an IP67 protection rating, making them highly resistant to dust and water immersion, ideal for solar panel installations.
What materials are used in the construction?
The contact material is tin-plated copper for excellent conductivity, and the insulation uses PPO material with a UL94-V0 flame class rating.
What is the operating temperature range?
These connectors are designed to operate reliably in extreme environments from -40ºC up to +125ºC.
Which cable sizes are compatible with the MC4 connectors?
They are compatible with standard solar cables of 2.5mm², 4.0mm², and 6.0mm² (AWG 14/12/10).
What type of connection system do they use?
They utilize a secure crimp connection system to ensure a stable and long-lasting electrical contact.
